| نام تجاری: | FUTURE |
| شماره مدل: | پمپ مه آلود 0.15 سی سی |
| مقدار تولیدی: | 100000 مجموعه |
| قیمت: | قابل مذاکره |
| جزئیات بسته بندی: | کارتن |
| شرایط پرداخت: | L/C، D/A، D/P، T/T، وسترن یونیون |
| Attribute | Value |
|---|---|
| Product Name | Mist Spray Pump |
| Standard Size | 1 inch (25.4mm ± 0.15mm) |
| Material | Tinplate / Aluminum |
| Dip Tube Length | Customized to can height |
| Finish Options | Plain / Clear Lacquer / Gold Lacquer |
| Inner Opening Diameter | 25.4 ± 0.07mm |
| Outer Opening Diameter | 31.2 ± 0.1mm |
| Inner Gasket Material | Buna / Neoprene / Butyl |
| Dip Tube Material | Polyethylene |
| Component | Material | Options / Specifications |
|---|---|---|
| Mounting Cup | Tinplate | With or without dimples |
| Mounting Cup | Aluminum | Gold lacquer / Microflex finish |
| Outer Gasket | Buna | -- |
| Inner Gasket | Buna / Neoprene / Butyl | -- |
| Stem | Nylon | 1×0.46mm, 1×0.51mm, 2×0.51mm, 2×0.61mm, 4×0.61mm |
| Spring | Stainless Steel | -- |
| Housing | Nylon | Φ4.3mm (Spray Area: 14.52mm²) |
| VPH Spray Area | -- | 6.7mm² |
| Steel Ball | Stainless Steel | Φ3.5mm |
